Survey Construction Procedures
Dates: 1st & 2nd February 2023
Sessions 1 & 2 (1st Feb): 10am to 5pm (AEDT - Sydney time), with a half-hour lunch break and two 15-minute breaks
Session 3 (2nd Feb): 10am to 1:15pm (AEDT - Sydney time), with a 15-minute break
Requirements: Dual monitors will be required so that the Trainer can be followed on one and the Course work can be done on the other. Alternatively, a second computer could also be used and projected to a screen or TV for viewing the Trainer.
An Internet Connection is required.
12d Model v15 and Codemeter drivers : 12d Model v15 Installation Document
Civil and Surveying Institute will supply a 12d Model licence and data to use for the course
2 seats available
14.0 SURVEY CONSTRUCTION PROCEDURES Course ID: 2DSCP
Prerequisites: Experience in 12d Model with completion of the One Day Survey Basics course or working through the ‘Getting Started for Surveying’ Manual is required.
Course Content: This course is only for experienced 12d Model surveyors.
• Importing Road design
• 12d Archive
• Analysis and checking
• String conversions and filtering
• Cross section creation
• Boxing creation
• Point cloud
• Stockpile volumes
• Progressive volumes
• Isopachs and shading
• Structure cad entry
• Uploading points / string
• Road upload
• Machine control upload
• House setout
• Road Construction
• Index & layout plans
• Long & Cross sections
• Volume reports
• Plot book
Please note courses may occasionally be cancelled or amended if trainers' availabilities change. If a change to a course occurs and you are unable to attend the new time, we will transfer your registration to the next available course.
All courses are non-refundable if you change your mind.
