Sorry - this product is no longer available

Survey Construction Procedures

Dates: 20th & 21st February 2024


Sessions 1 & 2: 10am to 5pm (AEDT - Sydney time) on 20th Feb, with two 15-minute tea breaks and a half-hour break for lunch

Session 3: 10am to 1:15pm (AEDT - Sydney time) on 21st Feb, with a 15-minute tea break


Requirements: Dual monitors will be required so that the Trainer can be followed on one and the Course work can be done on the other. Alternatively, a second computer could also be used and projected to a screen or TV for viewing the Trainer.

An Internet Connection is required.

12d Model v15 and Codemeter drivers : 12d Model v15 Installation Document

Civil and Surveying Institute will supply a 12d Model licence and data to use for the course

Course Places: 2 seats available
SKU: 240220_15SCP
$710.00 (AUD) excl GST


Prerequisites: Experience in 12d Model with completion of the One Day Survey Basics course or working through the ‘Getting Started for Surveying’ Manual is required.


Course Content: This course is only for experienced 12d Model surveyors.

• Importing Road design

• 12d Archive

• Genio


• Analysis and checking

• String conversions and filtering

• Cross section creation

• Boxing creation

• Point cloud

• Import

• Thinning

• Tinning

• Volumes

• Stockpile volumes

• Progressive volumes

• Isopachs and shading

• Setout

• Road

• Structure cad entry

• Uploading points / string

• Road upload

• Machine control upload

• Plotting

• House setout

• Road Construction

• Index & layout plans

• Long & Cross sections

• Volume reports

• Plot book



Please note courses may occasionally be cancelled or amended if trainers' availabilities change. If a change to a course occurs and you are unable to attend the new time, we will transfer your registration to the next available course.

All courses are non-refundable if you change your mind.
