Civil Design Features

Dates: 26th, 27th, 28th, and 29th September 2022

Time: 9am to 12:15pm (AEST - Sydney time), with a 15-minute break, each day

Requirements: Dual monitors will be required so that the Trainer can be followed on one and the Course work can be done on the other. Alternatively, a second computer could also be used and projected to a screen or TV for viewing the Trainer.

An Internet Connection is required.

12d Model v14 and Codemeter drivers : 12d Model v14 Installation Document

Civil and Surveying Institute will supply a 12d Model licence and data to use for the course

Course Places: Course Full
SKU: 2DCDF260922
*
*
*
*
*
*
*
*
$760.00 (AUD) excl GST

Summary:

This course follows on from the Civil Design Basics course. Understanding of basic road design is essential.

Prerequisites:

Experience in 12d Model with completion of the Civil Design Basics Course is required.

Course Content:

D02: Design, Advanced Modifiers

  • Import templates
  • Apply MTF defaults
  • Apply MTF Manager
  • Modifiers using smart chainages
  • Modifiers using layers
  • MTF features, Alias, Regions and copy and paste
  • View Properties, Favourites and Positions

D03: Design, MTF Snippets

  • What are Snippets?
  • Basic Snippet edits
  • Applying Snippets
  • Design TIN and SuperTIN

B06: Chains

  • Design Chain

D06: Design, MTF Boxing

  • Modifier boxing with layers
  • Asphalt surface, Kerb shapes and Subgrade layers

D07: Design, Tri-mesh Boxing

  • Boxing with Snippets
  • Subgrade TINs

T02: TINs and Volumes

  • Import raster

B05: Sharing

  • Making Models and TINs shared
  • Sharing in Models and TINs

A02: Super Alignment, Element Design

  • Design Toolbars
  • Create Super Alignment
  • Horizontal element geometry
  • Vertical element geometry
  • Named parts
  • Named positions

A04: Super Alignment, Computators

  • Using computator elements
  • Computator kerb return tool
  • Widening function
  • Modifiers with computators

A05: Super Alignment, Advanced Tools

  • Using Computators



Please note courses may occasionally be cancelled or amended if trainers' availabilities change. If a change to a course occurs and you are unable to attend the new time, we will transfer your registration to the next available course.

All courses are non-refundable if you change your mind.
