Drainage 2D - Introduction
Date: 15th, 16th, & 18th March 2021
Time: 1pm to 4:00pm (AEDT: Sydney Time) w/ 2 * 15 Minute Breaks
Course Places: 6 seats available
Prerequisites:
A working knowledge of the 12d interface is required. View control, model management, basic CAD drawing skills.
Course Content:
W10: Creating a rainfall on grid 2d model
• Create and run a TUFLOW model using the Roadflow quick start panel.
• Add ridges, gullies to enhance the 2D grid.
• Add roughness polygons for a second roughness.
• Link a 12d drainage model to the 2d grid. Review check files and results
• Review the grid z pts, ridges/gully, 1d-2d link and boundary control check files.
• Create and display tin varying grid tin results for water depths, velocity and hazard. This is done in plan, section and 3d perspective views.
• Create results legends and customise result colour bands. Time Results
• Create time plots of results of velocity, depth, water level and hazard.
• Create flow measurement lines to total the flow over the line. Visualisation and Fly Overs
• Create time lines viewing flooding from a stationary perspective
• Create flight and target paths for project flyovers of flood results.
