Track

Dates: 26th and 27th October 2022

Time: 1 to 4:15pm (AEDT - Sydney time), with a 15-minute break, each day

Requirements: Dual monitors will be required so that the Trainer can be followed on one and the Course work can be done on the other. Alternatively, a second computer could also be used and projected to a screen or TV for viewing the Trainer.

An Internet Connection is required.

12d Model v15 and Codemeter drivers : 12d Model v15 Installation Document

Civil and Surveying Institute will supply a 12d Model licence and data to use for the course

Course Places: 6 seats available
SKU: 221026_1DT
*
*
*
*
*
*
*
*
$420.00 (AUD) excl GST

19.0 TRACK

Course ID: 1DT

Prerequisites: For reasonably experienced 12d Users! Completion of the Design Basics Course and some experience/use after the course is essential plus a reasonable knowledge of Element Based Super Alignments. Experience in Rail Design & Rail Terminology is strongly recommended.

Course Content:

This course introduces users to the 12d Track Design Tools for rail design in 12d Model 15.

R01: Track

• Calculate the Track Centreline (3D) from the Surveyed Rails

• Use of Linear & Arc Regression (Though not actually part of the Track Tools, Regression is essential for developing a CL off Surveyed Data when no Design Data is available).

• Track Slew. Creating Reports, Spreadsheets & Diagrams & Plotting the Slew.

• Rail Profiles. Producing &/or Extracting a Rail Profile.

• Turnouts. Creating & Editing Turnouts & then Placing Turnouts.

• Chainage Equalities. Equality Types & Definitions. Their use + Inquiring on Equality Chainages

• Rail Cant. Cant design, Virtual Cant, Altering Speeds to Adjust Cant, Spreadsheets & Graphs & applying the Cant to the Rails.

• Plotting the Rails, Ballast & Sleepers. A quick look at producing a Circular (Bored) Tunnel.

• Setting and running structure gauge

• Some Long Section Plot Settings/Tweaks.

Please note courses may occasionally be cancelled or amended if trainers' availabilities change. If a change to a course occurs and you are unable to attend the new time, we will transfer your registration to the next available course.

All courses are non-refundable if you change your mind.
