Two-Day Survey Construction Procedures
Date: 21st & 22nd November 2022
Time: 10am to 5pm (AEDT - Sydney Time) Sessions 1&2, 10am to 12:15pm (AEST - Sydney Time) Session 3 (3 x 3-hour sessions with 2 x 15-minute breaks in each**)
**Please note Day 1 also includes a half-hour break for lunch
Requirements: Dual monitors will be required so that the Trainer can be followed on one and the Course work can be done on the other. Alternatively, a second computer could also be used and projected to a screen or TV for viewing the Trainer.
An Internet Connection is required.
12d Model v14 and Codemeter drivers : 12d Model v14 Installation Document
Civil and Surveying Institute will supply a 12d Model licence and data to use for the course
Course Places: 6 seats available
14.0 SURVEY CONSTRUCTION PROCEDURES Course ID: 2DSCP
Prerequisites: Experience in 12d Model with completion of the One Day Survey Basics course or working through the ‘Getting Started for Surveying’ Manual is required.
Course Content: This course is only for experienced 12d Model surveyors.
• Importing Road design
• 12d Archive
• Analysis and checking
• String conversions and filtering
• Cross section creation
• Boxing creation
• Point cloud
• Stockpile volumes
• Progressive volumes
• Isopachs and shading
• Structure cad entry
• Uploading points / string
• Road upload
• Machine control upload
• House setout
• Road Construction
• Index & layout plans
• Long & Cross sections
• Volume reports
• Plot book
Please note courses may occasionally be cancelled or amended if trainers' availabilities change. If a change to a course occurs and you are unable to attend the new time, we will transfer your registration to the next available course.
All courses are non-refundable if you change your mind.
