Utility Modelling and Design

Dates: 12th, 13th, 14th November 2024

Time: 10am to 1:30pm (AEDT - Sydney time), with a 15-minute break, each day



[Please note the current price of $500 +GST for this course is a special introductory rate.]



Course Places: 6 seats available
SKU: 241112_15UTIL
*
*
*
*
*
*
*
*
$500.00 (AUD) excl GST

Summary:

This course introduces users to importing, mapping and visualising surveyed utility data, using attributes for modelling and manipulation of data, then exporting attributes with the data. The course then progresses to designing new utilities using several tools within 12d Model to give the user an understanding of the options available as well as their pros and cons.



Prerequisites:

Experience in 12d Model, with completion of the Civil Design Basics course.



Course Content:

B07: Attribute Management

  • Attributes
  • Map files
  • Importing utility data
  • Chains for data import
  • Translating by attribute depth
  • Replacing attribute values
  • The Attribute Manipulator
  • Quantity reports
  • Exporting Water string attributes
  • Labelling
  • Clash detection



D10: Utility Design

  • Designing utilities using Super Alignments (IP and Element methods)
  • BIM objects create/edit/apply
  • BIM objects map files
  • Utilities within the MTF
  • Create/edit service conduit/water main
  • Trenching of Water strings
  • Plotting



Please note courses may occasionally be cancelled or amended if trainers' availabilities change. If a change to a course occurs and you are unable to attend the new time, we will transfer your registration to the next available course.

All courses are non-refundable if you change your mind.
